CHAIN CONVEYOR



Chain conveyors are sturdy enough to convey the most difficult bulk materials. These conveyors are available in capacities up to 400 m3/h. This method of product conveying is exceptionally suitable for conveying over long distances.



Features Chain Conveyors

- S235 steel trough, fully enclosed design

- Primer and paint finish

- Geared drive units

- Flexible coupling

- HPME wear plate

- Guide strips (C45)

- Overflow valve

- Chain tensioner



Special Executions

- Executed in AISI304

- Executed in galvanized S235 steel

- All-weather features like drive unit housing and shaped covers

- Speed sensor

- ATEX22 zoned drive units

- Intermediate outlets

- Recirculation head with intermediate bottom

- Inlet flow regulation slide

- Protective chain hood for intake applications

- Spotfilter



The following free-flowing products can be handled with a chain conveyor:

- Grains

- Granulates

- Pellets

- Flakes

- Meals

- And many other products
