BUCKET ELEVATOR



Benefits

- Efficiently and simply designed.

 - Totally enclosed.

 - Custom-built to suit individual

requirements.

- Provides efficient high capacities.



Optional extras

- Stainless steel construction.

- Squirrel cage pulleys.

- Rubber lagged pulleys.

- Plastic buckets.

- Perforated or vented buckets.

- Self-cleaning boot section.

- Revolution counter.

 - Backstop to prevent reverse rotation.

- Explosion relief-panels.



Application

 The bucket-elevator is designed for vertically

 handling a variety of dry, free flowing bulk

 materials efficiently and with high capacities.



Operation

 The buckets are carried by a belt all

 contained on standard elevator legs. The

 belt-elevator is exceedingly suitable as a

 high capacity bucket-elevator. The speed

 varies according to the kind of product being

 transported, from 1,5 to 3,5 meter/sec.



Construction

 - Jig welded angle flanges assure perferct

 alignment of legging sections.

- Boot section with bolted side panels and

 slide cleanouts. - Rubber belt.

 - High capacity buckets.

- Inspection door.

- Crowned head pulley.

- Crowned boot pulley.

- Dust-tight take-ups.
